Brand Name : XCMG
Model Number : GR1803
Certification : CCC/ISO/CE
Place of Origin : CHINA
MOQ : 1 unit
Price : negociable
Payment Terms : LC/TT
Supply Ability : 1000UNITS/MONTH
Delivery Time : 25 work days
Packaging Details : nude, maxed on deck
Brand : XCMG
Model : GR1803
Engine : Cummins 6CTA8.3
Horse Power : 138KW
Operating Weight : 5400kgs
Blade Size : 3965*610mm
Color : Yellow
Basic specification | |
Engine model | Cummins 6CTA8.3 |
Rated power/speed | 138kW/2200rpm |
Dimension(LxWxH) | 8900x2625x3470mm |
Operating weight(Standard) | 15400kg |
Performance specification | |
Travelling speed ,forward | 5,8,11,19,23,38 km/h |
Travelling speed ,reverse | 5,11,23 km/h |
Tractive force(f=0.75) | 79KN |
Max. gradeability | 20% |
Tire inflation pressure | 260 kPa |
Working hydraulic pressure | 16 MPa |
Transmission pressure | 1.3~1.8MPa |
Operating specification | |
Max. steering angle of front wheels | ±50° |
Max. lean angle of front wheels | ±17° |
Max. oscillation angle of front axle | ±15° |
Max. oscillation angle of balance box | 15 |
Frame articulation angle | ±27° |
Min. turning radius using articulation | 7.3m |
Blade | |
Maximum lift above ground | 450mm |
Maximum depth of cutting | 500mm |
Maximum blade position angle | 90° |
Blade cutting angle | 28°—70° |
Circle reversing rotation | 360° |
Moldboard Length X height | 3965*610mm |
XCMG GR180 Motor Grader
1. Engine: Cummins 6CTA8.3
2. Operating weight: 15400kg
3. Blade size:3965*610mm
XCMG GR180 Motor Grader
XCMG GR Series Motor Graders are mainly used in ground leveling, cannlling, scraping, earthmoving, scarification or snow removal work on road, airfield, farmland, and so on .
They are necessary construction machines for national defense engineering, mine construction, town and country roads building, and farmland improvement.
Performance and characteristic:
1. New appearance design.
2. The articulation frame is adopted and macthed with the steering of the front wheel, with small turning radius, maneuvering and flexible.
3. The electro-hydraulic contrals the power shift gearbox, with 6 ahead box and 3 back gears.
4. The international mataching hydraulic parts are adopted, with reliable operation.
5. The motions of the knife are fully hydraulically controlled.
6. The rear axle is the three-section driving axle which is provide with the NO-SPIN self-locking differential mechanism.
7. The manipulation table and seats are adjustable. The arrgement of the manipulation handle and instruments are reasonable, with convenient application, and the comfprt of driving is improved.
8. The cab is grand and nice, with wide eyeshot and good sealing.
9. The front bolldozing plate,rear scarification device, front scarification harrow and automatic leveling device can be added.
Pre-service:
After-sale service:
![]() |
Gr1803 XCMG Motor Grader Road Construction Vehicles With Cummins 6CTA8.3 Engine Images |
