SINOTRUK HOWO 6x4 12T Boom Truck Crane with 20.5m Max. Lifting Height Optional color
Description:
The engine adopt 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection.Adopting full hydraulic transmission, it can bring the power of engine into full play amply.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.Rich experience and well after-sale service.
The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.
Packing:
Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.
Competitive Advantage:
1. The price is competitive.
2. All colors are available according to your choice.
3. 30-45 work days production period.
4. Professional team for customs services.
5. Technique support and training for your stuff.
6. Professional and many oversea experience after-sales service team.
| GVW25000kg Driving Type 6x4 |
| Model | CLW5257JSQZ |
| Cab | SINOTRUK HW76 Lengthen cab, single bunk, new type seat, adjustable steering wheel ,EURO new type heating & ventilating system, German VDO instruments, safety belts, exterior sun visor, stereo radio/cassette recorder, air conditioner |
| Engine(Hp) | 336 |
| Power(Kw) | 247 |
| Wheelbase | 5825+1350 |
| Front/Rear Suspension | 1500/3295 |
| Steering | Power steering |
| Approach/departure angle | 16/9 |
| Wheels & tire | 11.00r20 |
| Tire number | 10+1 |
| Cargo Dimensions(mm) | 8000,8400X230X600 |
| Cubage (m3) | |
| RHD or LHD | optional |
| Overall Dimensions(mm) | 12000×2500×3850 |
| Curb weight (Kg) | 16270 |
| Engine | Model | WD615.69 |
| Horsepower | 336 |
| Maximum output Kw | 247 |
| Maximum torque N.m | 1350 |
| Type | 6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine |
| Displacement | 9.726L |
| Sinotruk brand, Euro 2 |
| Driving passenger | 2,3 |
| Transmission | HOWO 15710 ,10 speed forward and 2 reverse, manual |
| Front Axle | 9T |
| Rear Axle | 16T |
| Brake System | air brake ,exhaust brake |
| Color and LOGO | customized |
| Electric system | 24V |
| crane | Model | SPS30000(sany) | Oil tank capacity | 200L |
| Max lifting height | 20.5m | Max lifting moment | 30T.m |
| Max working radius | 18.1m | Length of the basic boom | 5.6m |
| Max loading | 12000kg | Weight of crane | 4650kg |
| Type | Straight arm | Recommended hydraulic flow | 100L/min |
| Arms number | 5 | Outrigger space | 6000mm |
| Turning angle | 360 | Rated hydraulic pressure | 29MPa |
| Standard configuration | truck crane equipped between the cabin and van body, mechanical leg |
| Optional configuration | Any other famous brand crane, such as XCMG, SANY, it can also be equipped in the rear of the truck, hydraulic legs, aerial working seat is optional. |
