HOWO 336 HP Euro 2 6×4 18 m3 water tank truck with ZF8098 Steering gear box
Description:
HOWO 336 HP Euro 2 6×4 18 m3 water tank truck adopt SINOTRUK WD615 series of 6-cylinder in line, 4-stroke, water-cooled, turbo-charged inter-cooled,direct injection engine.
And the main parts adopt international well-known brands,for example German ZF8118 steering,German WABCO brake control system,HOWO series of transmission,BEHR water tanker,safety and reliable.
And the many color choice, and the best cost and performance, deeply favored by oversea customers.
It can transport kinds of bulk cargo in normal roads and tough roads.
Packing:
Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.
Competitive Advantage:
1. The price is competitive.
2. All colors are available according to your choice.
3. 30-45 work days production period.
4. Professional team for customs services.
5. Technique support and training for your stuff.
6. Professional and many oversea experience after-sales service team.
| Truck model | ZZ1257M4647 |
| Dimension(Lx W xH)(unloaded) | 9895×2496×3668mm |
| Tanker volume(m3) | 18m3 |
| Tank body | thickness:5mm, material:carbon steel, sprinkling equipment both in front and in rear; special anti-corrosion treatment |
| Approaching angle/Departure angle(°) | 13.5/11.5 |
| Overhang(front/rear) (mm) | 1500/2445 |
| Wheel base (mm) | 4600+1350 |
| Max speed(km/h) | 75 |
| Curb weight(kg) | 12400 |
| Rated Loading Weight(kg) | 12450 |
| Engine | Model | WD615.69,water-cooled,four strokes,6 cylinders in line with water cooling,directly injection |
| | Fuel type | Diesel |
| | Horse Power, max(kw/rpm) | 336HP |
| | Emission | EURO 2 |
| Fuel tanker capacity | 300 |
| Transmission | Model | HW15710, 10 forward, 2 reverse |
| Brake system | Service brake | Dual circuit compressed air brake |
| | Parking brake | spring energy, compressed air operating on rear wheels |
| Steering system | Model | ZF8098 |
| Front axle | HF7 , Steering with double T-cross section beam |
| Rear axle | ST16 |
| Color | Optional |
| Tyre | 12.00R20 |
| Tanker volume | 15000L |
| Electrical system | Battery | 2X12V/165Ah |
| | Alternator | 28V-1500kw |
| | Starter | 7.5Kw/24V |
| Cab | HOWO76 cab, (single sleeping, with air-condition), all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers |
