Brand Name : HOWO A7
Model Number : ZZ4257N3247N1B
Certification : ISO9001
Place of Origin : JINAN CITY OF CHINA
MOQ : 1 UNIT
Price : Negotiable
Payment Terms : L/C, T/T
Supply Ability : 500 units/month
Delivery Time : 30-45 work days
Packaging Details : Nude
Model : ZZ4257N3247N1B
Cab : A7-P cab
Engine : WD615.47, Euro 2, 371 HP
Overall dimension : 6985x2550x3800 mm
Oil Tank : Square type-400L Aluminum alloy fuel tank
Transmision : HW19710, 10F & 2R
ZZ4257N3247N1B SINOTRUK HOWO EURO II tractor truck with HW19710 transmision
Description:
HOWO 6x4 Euro 2 tractor truck now is the best products in overseas market, the frame adopt U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members
Front suspension adopt 10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer.Rear suspension adopt 12 leaf semi-elliptic springs, bogie spring and stabilizer.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.
Competitive Advantage:
1. Flexible and convenient logistic service.
2. Excellent and high-quality control
3. Rich experience and well after-sale service.
4. Long lasting working life time.
5. Sufficient storage.
6. Professinal Sales Team of trucks. Our target is not selling trucks, we help customers choose the best suitable trucks.
7. Fast production period, and quick arrangement of delivery.
Description:
Sinotruk Howo A7 6x4 Tractor Truck | |
Chassis Model | ZZ4257N3247N1B (Left Hand Driving Type) |
Cabin | A7-P cab, with one sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn,air conditioner, with transverse stabilizer, with 4-point support fully floating suspension + shock absorber. |
Engine | Make: SINOTRUK Diesel 4-stroke direct injection diesel engine Engine model: WD615.47, Euro 2, 371 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L |
Transmission | HW19710, 10F & 2R. |
Steering | ZF8098, hydraulic steering with power assitance |
Front Axle | HF9, 1x9000 KGS Steering with doubleT-cross section beam |
Rear Axle | HC16, 2x16000 KGS, drum brake equipped with ABS system. Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles. Ratio:4.42 |
Propeller Shaft | Double universal joint propeller shaft with gear-shaped coupling flange |
Chassis | Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer |
Brake | Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake |
Electrics | Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
Tyres | 12.00R20, tubeless tires with 1 spare tires. |
Fuel Tank | 400L |
Overall Dimension | 6985x2550x3800 mm |
![]() |
HW19710 Transmission Tractor Trailer Truck Left Hand Driving Type ZZ4257N3247N1B Images |
