China Lower Price Heavy Duty 10/12 Wheels Sprinkler Sanitation Vehicle 20000/30000liters

Brand Name : HOWO

Model Number : HOWO

Certification : ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE

Place of Origin : China

MOQ : 1UNIT

Price : NEGOTIABLE

Payment Terms : L/C,T/T

Supply Ability : 500 units/month

Delivery Time : 40 worker days

Packaging Details : Nude

Product name : Howo 6*4 spinkler

Fuel : Diesel

Engine Capacity : ＞8L

Water Sprinkle Width : 14m

Gearbox : 5 Forward & 1 Reverse

Tire Certification : ECE, GCC, ISO, DOT

Color : Yellow, Red, White, Blue, Optional

Contact Now

China Lower Price Heavy Duty 10/12 Wheels Sprinkler Sanitation Vehicle 20000/30000liters


Product Description

This water sprinkler tanker is a versatile and efficient solution for various road watering and dust - suppression tasks. It features multiple Sinotruk engine options, including WD615.62, WD615.87, WD615.69, and WD615.47, with horsepower ranging from 266hp to 371hp, catering to diverse performance requirements. The tank volume is in the range of 18,000 - 20,000 liters, enabling extended operation without frequent water refills. The vehicle delivers low oil consumption for good economic efficiency.
A Chinese famous brand pump is installed to ensure reliable water delivery. The sprinkler system features self - suction and self - discharge functions, front flushing and sprinkling, side spurting, and a post - positioned work table. It also has a high - pressured sprinkler that can adjust water spraying between columnar and fog shapes. As an added option, a fire pump and firefighting accessories can be installed.BV ISO CCC approved and can accept customes' OEM customized.
The tanker is especially suitable for municipal administration environmental sanitation departments and large - scale industrial and mining enterprises.
The water sprinkler tanker features a tank made from carbon steel sheet Q235 - A, stainless steel, or aluminum alloy. It is equipped with the well - known pump and the main parts are automatically welded for durability. Its sub - crossbeam is made of rectangular steel sheet with a thickness exceeding 5mm, produced in one single process. The painting has high tolerance and adhesion, ensuring the tank remains in good condition for over five years.
Vehicle Main Dimensions Overall dimensions (L x W x H)mm8 950×2496×3348
Wheel base (mm) 4600+1350
Wheel track (front/rear) (mm) 2022/1830
Approach/Departure angle(°) 16/14
Weight in KGS Tare Weight 7420
payload 15000KGS
Front axles loading capacity 1x7000
Rear axles loading capacity 1x16000
Max. driving speed(km/h) 90
Engine Brand Sinotruk
Model WD615.62
Type 4-stroke direct injection , 6-cylinder in-line, turbo-charging and inter-cooling
Horse Power(HP) 266 HP
Emission standard Euro-II
Gearbox 10 Forwards gear & 2 reverse gear
Steering power steering ZF8098 from Germany
Tire 295/80R22.5 tubeless tire, 7 pieces including one spare tire
Tank specification 15,000 liters, tank thickness is 5 mm, seal is 6 mm
Equipped with front(rear,side)sprinkler(sprinkling width>14m )
Equipped with rear working platform with water cannon (range>28m)
Equipped with pump(suction lift>6m)
Equipped with fire valve,water valve,and filter gauze
